Documentation
- Vacuum Machine CatalogPDF · 5.9 MB
- Operating instructionPDF · 681.9 KB
- Datasheet MAX 42 Z2001PDF · 987.8 KB
Manufacturer PDFs. They open in a new tab on vacuum-boss.com.
Manufacturer data. Subject to change and printing errors.
Options and accessories
Tick what you need. We send the list with your request, so the quotation matches the machine you have in mind.
No options selected — ask us about the standard machine, or tick what you need.
Not sure which options you need? Tell us what you pack and we will put a configuration together with you.
Find the right size
Every model with the sizes that decide between them. Switch range to look at another type of machine.
Basic Line7Tabletop machines7Floorstanding machines6Double chamber machines5Automatic machines3Vertical and special purpose machines10Tray sealers14Shrink dip tanks and shrink tunnels7
- AVS 1600
- MAX-F 50 D
- V 42 VA
- V 50 VA
- V 810 VA
- VX 630 VA
- NE 14 VA
- NE 63 VA
- Clipapparaat handmatig
- Clipapparaat elektrisch
Compare the Tabletop machines range
Every model in this range side by side. Click a model to open its page.
| Specification | MINI-T 10 D | MINI MAX | MAX | MAX 36 | MAX 42 | MAX 46-S | MAX XL |
|---|---|---|---|---|---|---|---|
| Fabrikant | Boss | Boss | Boss | Boss | Boss | Boss | Boss |
| Kamerafmetingen | 285 x 350 x 105 mm | 285 x 350 x 150 mm | 350 x 400 x 125/180 mm | 815 x 390 x 105 mm | 450 x 460 x 210 mm | 650 x 475 x 210 mm | 580 x 350 x 125 mm |
| Machineafmetingen | 360 x 505 x 330 mm | 360 x 490 x 330 mm | 430 x 550 x 340/400 mm | 910 x 580 x 410 mm | 540 x 560 x 410 mm | 750 x 630 x 410 mm | 670 x 500 x 340 mm |
| Vacuümpomp | 4 m³/h | 8 m³/h | 10 m³/h of 16 m³/h | 21 m³/h | 16 m³/h of 21 m³/h | 21 m³/h | 10 m³/h |
| Gewicht | 28 kg | 33 kg | 48 kg of 50 kg | 95 kg | 69 kg of 72 kg | 95 kg | 60 kg |
| Voedingsspanning | 1 fase, 230 V, 50 Hz | 1 fase, 230 V, 50 Hz | 48 kg of 50 kg | 1 fase, 230 V, 50 Hz | 1 fase, 230 V, 50 Hz | 1 fase, 230 V, 50 Hz | 1 fase, 230 V, 50 Hz |
| Besturing | Z 2001 Sensor | Z 2001 Sensor | Z 2001 Sensor | Z 2001 Sensor | Z 2001 Sensor | Z 3000 of Z 2001 Sensor | Z 2001 Sensor |
| Seallengte | – | 260 mm | 320 mm | 360/720 mm | 420 mm | 460 mm | 320 mm |
| Sealsysteem | – | dubbele sealnaad of enkele scheidingssealnaad | dubbele sealnaad of enkele scheidingssealnaad | dubbele sealnaad of enkele scheidingssealnaad | dubbele sealnaad of enkele scheidingssealnaad | dubbele sealnaad of enkele scheidingssealnaad | dubbele sealnaad of enkele scheidingssealnaad |
Sealing bar
The length of seal the machine makes in one cycle. It sets the widest bag you can close in a single go.
See the sealing systemsFeatures
- High-quality Busch vacuum pump
- Deep-drawn vacuumchamber
- Maintenance construction
- Cable-free welding-bar construction
- Starter kit with consumables (teflon tape, welding wire) included
